UTRIX-16 Multi-Use PDF Logger at a Distance

UTRIX-16 Multi-Use PDF Logger at a Distance


Data logger with integral USB connector. The LogTag® UTRIX-16 satisfies the growing need for a cost effective and reliable multi-use temperature recorder with built-in USB.

Product Summary

The LogTag® UTRIX-16 requires no special hardware or proprietary software to access the recorded data and can generate a fully detailed PDF report. It stores real-time temperature readings over a measurement range of -30 °C to +70 °C, displays user-configurable alerts, and comes with an integrated, long-life USB connector. The UTRIX-16 is enclosed in the same robust and durable polycarbonate case common to other LogTag products.

Product Highlights

  • Automatically generates a PDF report and an Excel data file - no special download software required.
  • Automatically generates an encrypted LogTag data file - for a more detailed analysis and to comply with FDA CFR21 Part 11.
  • Fully user configurable via LogTag Analyzer for individual alarm settings, start options, trip length and log interval.
  • Durable, reliable USB connector with gold plated contacts, designed for multiple insertions.
  • Up to 16,129 recordings - provides over 3 months logging at 10 minute sample intervals.
  • Suitable for any multi-use application where the recorder can be recovered and reused.


Technical Specifications

Model UTRIX-16
Measurement Range -30 °C to +70 °C
Rated Temperature Reading Accuracy Better than ±0.5 °C for -20 °C to +40 °C
Better than ±0.7 °C for -30 °C to -20 °C & +40 °C to +60 °C
Better than ±0.8 °C for +60 °C to +70 °C
Capacity 16,129 real time temperature recordings, non-volatile
Sampling Interval Configurable from 30 seconds to 18 hours
Start Options Push button start or specific date/time
Start up delay Configurable from 1 minute to 72 hours
Environmental IEC 60529: IP64 with USB cap fitted
Power Source 3V Lithium battery- non replaceable
Battery Life 2-3 years of normal use, based on 15 minute logging
and monthly data download
Size 93 mm (H) x 54.5 mm (W) x 8.6 mm (T) including USB cap
Weight 35 g
Case Material Polycarbonate
Alarm Functions High/low, single, consecutive and cumulative alarm
events, 'OK'/'ALERT' indicators
Connection Interface USB 2.0, High durability, metal A-type plug
Software Adobe Reader, LogTag Analyzer® 2.6 or higher
